唐山市中機機械設備有限責任公司生產的液壓經濟型數控折彎機，型號：WC67Y/K-40T/2500，品牌：中機機械，產地：河北·唐山，廠商性質：生產商。
產品介紹
液壓經濟型數控折彎機性能特點：
= 在裝夾上模過程中僅需要扳轉手柄，即可裝夾上模節約裝夾時間。
= 裝夾中由半圓鍵與上模裝夾面接觸，改善了上模的夾緊條件，改變了普通夾具中存在的局部接觸或線接觸的狀況，使上模夾緊穩固不易偏移。
= 能夾持小尺寸的散刀，解決了普通夾具夾時散刀有松動的現象。
液壓經濟型數控折彎機技術參數：
| 規格型號 | 公稱壓力 | 工作臺長度 | 立柱間距離 | 開啟高度 | 喉口深度 | 滑塊行程 | 主電機功率 |
| WC67Y/K-40T/2500 | 100 | 2500 | 2060 | 335 | 200 | 80 | 4 |
| WC67Y/K-63T/2500 | 630 | 2500 | 2060 | 360 | 250 | 100 | 5.5 |
| WC67Y/K-63T/3200 | 630 | 3200 | 2600 | 360 | 250 | 100 | 5.5 |
| WC67Y/K-80T/2500 | 800 | 2500 | 2060 | 390 | 250 | 120 | 7.5 |
| WC67Y/K-80T/3200 | 800 | 3200 | 2600 | 390 | 250 | 120 | 7.5 |
| WC67Y/K-80T/4000 | 800 | 4000 | 3100 | 390 | 250 | 120 | 7.5 |
| WC67Y/K-100T/2500 | 1000 | 2500 | 2060 | 390 | 320 | 150 | 7.5 |
| WC67Y/K-100T/3200 | 1000 | 3200 | 2600 | 390 | 320 | 150 | 7.5 |
| WC67Y/K-100T/4000 | 1000 | 4000 | 3100 | 390 | 320 | 150 | 7.5 |
| WC67Y/K-100T/5000 | 1000 | 5000 | 4100 | 390 | 320 | 150 | 7.5 |
| WC67Y/K-100T/6000 | 1000 | 6000 | 4800 | 390 | 320 | 150 | 7.5 |
| WC67Y/K-125T/2500 | 1250 | 2500 | 2060 | 390 | 320 | 200 | 7.5 |
| WC67Y/K-125T/3200 | 1250 | 3200 | 2600 | 390 | 320 | 200 | 7.5 |
| WC67Y/K-125T/4000 | 1250 | 4000 | 3100 | 390 | 320 | 200 | 7.5 |
| WC67Y/K-125T/5000 | 1250 | 5000 | 4100 | 390 | 320 | 200 | 7.5 |
| WC67Y/K-125T/6000 | 1250 | 6000 | 4800 | 390 | 320 | 200 | 7.5 |
| WC67Y/K-160T/2500 | 1600 | 2500 | 2060 | 450 | 320 | 200 | 11 |
| WC67Y/K-160T/3200 | 1600 | 3200 | 2600 | 450 | 320 | 200 | 11 |
| WC67Y/K-160T/4000 | 1600 | 4000 | 3100 | 450 | 320 | 200 | 11 |
| WC67Y/K-160T/5000 | 1600 | 5000 | 4100 | 450 | 320 | 200 | 11 |
| WC67Y/K-160T/6000 | 1600 | 6000 | 4800 | 450 | 320 | 200 | 11 |
| WC67Y/K-200T/3200 | 2000 | 3200 | 2600 | 500 | 400 | 200 | 15 |
| WC67Y/K-200T/4000 | 2000 | 4000 | 3100 | 500 | 400 | 200 | 15 |
| WC67Y/K-200T/5000 | 2000 | 5000 | 4100 | 500 | 400 | 200 | 15 |
| WC67Y/K-200T/6000 | 2000 | 6000 | 4800 | 500 | 400 | 200 | 15 |
| WC67Y/K-250T/3200 | 2500 | 3200 | 2600 | 525 | 400 | 200 | 18.5 |
| WC67Y/K-250T/4000 | 2500 | 4000 | 3100 | 525 | 400 | 200 | 18.5 |
| WC67Y/K-250T/5000 | 2500 | 5000 | 4100 | 525 | 400 | 200 | 18.5 |
| WC67Y/K-250T/6000 | 2500 | 6000 | 4800 | 525 | 400 | 200 | 18.5 |
| WC67Y/K-300T/3200 | 3000 | 3200 | 2600 | 525 | 400 | 200 | 22 |
| WC67Y/K-300T/4000 | 3000 | 4000 | 3100 | 525 | 400 | 200 | 22 |
| WC67Y/K-300T/5000 | 3000 | 5000 | 4100 | 525 | 400 | 200 | 22 |
| WC67Y/K-300T/6000 | 3000 | 6000 | 4800 | 525 | 400 | 200 | 22 |
| WC67Y/K-400T/3200 | 4000 | 3200 | 2600 | 640 | 400 | 250 | 37 |
| WC67Y/K-400T/4000 | 4000 | 4000 | 3100 | 640 | 400 | 250 | 37 |
| WC67Y/K-400T/5000 | 4000 | 5000 | 4100 | 640 | 400 | 250 | 37 |
| WC67Y/K-400T/6000 | 4000 | 6000 | 4800 | 640 | 400 | 250 | 37 |
| WC67Y/K-500T/4000 | 5000 | 4000 | 3100 | 640 | 400 | 300 | 45 |
| WC67Y/K-500T/5000 | 5000 | 5000 | 4100 | 640 | 400 | 300 | 45 |
| WC67Y/K-500T/6000 | 5000 | 6000 | 4800 | 640 | 400 | 300 | 45 |
| WC67Y/K-600T/4000 | 6000 | 4000 | 3100 | 640 | 400 | 300 | 45 |
| WC67Y/K-600T/5000 | 6000 | 5000 | 4100 | 640 | 400 | 300 | 45 |
| WC67Y/K-600T/6000 | 6000 | 6000 | 4800 | 640 | 400 | 300 | 45 |
| WC67Y/K-700T/4000 | 7000 | 4000 | 3100 | 640 | 500 | 300 | 55 |
| WC67Y/K-700T/5000 | 7000 | 5000 | 4100 | 640 | 500 | 300 | 55 |
| WC67Y/K-700T/6000 | 7000 | 6000 | 4800 | 640 | 500 | 300 | 55 |
| WC67Y/K-700T/7000 | 7000 | 7000 | 5600 | 640 | 500 | 300 | 55 |
| WC67Y/K-700T/8000 | 7000 | 8000 | 6200 | 640 | 500 | 300 | 55 |
| WC67Y/K-800T/6000 | 8000 | 6000 | 4800 | 800 | 500 | 400 | 2*37 |
| WC67Y/K-800T/7000 | 8000 | 7000 | 5600 | 800 | 500 | 400 | 2*37 |
| WC67Y/K-800T/8000 | 8000 | 8000 | 6200 | 800 | 500 | 400 | 2*37 |
| WC67Y/K-800T/10000 | 8000 | 10000 | 7800 | 800 | 500 | 400 | 2*37 |
| WC67Y/K-800T/12000 | 8000 | 12000 | 9400 | 800 | 500 | 400 | 2*37 |
| WC67Y/K-1000T/6000 | 10000 | 6000 | 5600 | 800 | 600 | 400 | 2*45 |
| WC67Y/K-1000T/8000 | 10000 | 8000 | 6200 | 800 | 600 | 400 | 2*45 |
| WC67Y/K-1000T/10000 | 10000 | 10000 | 7800 | 800 | 600 | 400 | 2*45 |
| WC67Y/K-1000T/12000 | 10000 | 12000 | 9400 | 800 | 600 | 400 | 2*45 |
